Features:

●Adopt Honda single-cylinder air-cooled gasoline generator set, stable and reliable;

●High range (20-25 meters), good penetration;

●Using automatic control and remote control operation (can be operated in the cab), the operation is simple and convenient;

●Ultra-low volume, low volume, constant spray, saving medicine, high drug utilization rate, and low pollution;

●Stable combustion smoke injection device can be installed;

● Equipped with a 50-meter medicine delivery tube for constant spraying;

●The spray barrel swings up and down automatically, and the level is manually adjusted (automatic steering device can be added);

●Low labor intensity and high working efficiency (can prevent and control 100-150 acres per hour). Low control cost;

●The sprayer can be separated from the car body to improve the utilization rate of the car;

●At leisure, it can be used as a generator;

●According to customer requirements, pickup trucks, small four rounds and three rounds can be equipped (pickups are available from Zhengzhou Nissan, Qingling, Great Wall, etc.).

● Passed the national 3C compulsory certification and the appraisal of agricultural machinery promotion by the Ministry of Agriculture.

Scope of application:

●Prevention and control of diseases and insect pests in tall forest trees such as the Three North Shelterbelt, Field Net Shelterbelt, Fast-growing Timber Poplar Forest, Economic Forest, Greening Trees on Both Sides of Highways, and Urban Street Trees.

●Quickly kill locusts and control large-scale agricultural and forestry diseases and insect pests.

●Sterilization and deworming of large-scale outdoor areas such as urban greening, garbage dumps, and large stadiums.

Main parameters:

model：6HW-50A

Power：6.6KW/3600rpm

Fog spectrum range：50-150μm

Nozzle angle：vertical -15°-85°   Level0°-270°

Vehicle speed：5-10Km/h

Spray volume：40-600L/h

Range： vertical20-25m,Level35-45m

Net Weight：400kg

Medicine box capacity：Standard 400L (can be customized according to customer requirements)

Dimensions：1580×1070×1820mm
