Features:

●Using imported four-cylinder diesel generator set, the machine is stable, reliable and low noise;

●Long range (vertical range 30-35 meters, horizontal range 55-65m), good penetration;

●Using automatic control and remote control operation (can be operated in the cab), the operation is simple and convenient;

●Ultra-low volume, low volume, constant spray, saving medicine, high drug utilization rate, and low pollution;

●Stable combustion smoke injection device can be installed;

● Equipped with a 100-meter medicine delivery tube for constant spraying;

●Low labor intensity, high working efficiency (can prevent 500-650 acres per hour), low control cost;

●The sprayer can be separated from the car body to improve the utilization rate of the car;

●At leisure, it can be used as a generator;

●It can be equipped with trucks above 2.5T;

● Passed the national 3C compulsory certification and the appraisal of agricultural machinery promotion by the Ministry of Agriculture;

Scope of application:

●Prevention and control of diseases and insect pests in tall forest trees such as the Three North Shelterbelt, Field Net Shelterbelt, Fast-growing Timber Poplar Forest, Economic Forest, Greening Trees on Both Sides of Highways, and Urban Street Trees.

●Quickly kill locusts and control large-scale agricultural and forestry diseases and insect pests.

●Sterilization and deworming of large-scale outdoor areas such as urban greening, garbage dumps, and large stadiums.

Main parameters:

Model: 6HW-80

Supporting power: 22.4KW/3000rpm

Fog spectrum range: 50-150μm

Rotary angle of spray barrel: vertical angle -15°-85° horizontal angle 0°-270°

Vehicle speed: 10-15Km/h

Spray volume: 200-1500L/h

Range: vertical 30-35m, horizontal 55-65m

Net weight: 1500kg

Medicine box capacity: 2000L

Dimensions: 2500×1310×2150mm (whole machine) 1740×1370×1650mm (medicine box)
